| Property | Value |
|---|---|
| Viscosity (mPa∙s) | 54,000 |
| Thixotropic Index | 4.4 |
| Specific Gravity (g/cm³) | 1.3 |
| Pot Life @ 25ºC | 3 days |
| Shelf Life @ -20°C | 183 days |
| Cure Type | Condition | Details |
|---|---|---|
| UV Cure | High-pressure mercury lamp | Wavelength: 220–380 nm, Intensity: 100 mW/cm² |
| Exposure Time | 2 sec | 0.4 mm depth |
| 10 sec | 0.8 mm depth | |
| Heat Cure | 80°C | 30 minutes |
| Property | Value |
|---|---|
| Hardness (Shore D) | 90 |
| CTE (ppm/°C) Below Tg | 45 |
| CTE (ppm/°C) Above Tg | 156 |
| Glass Transition Temp (°C) | 90 |
| Modulus @ 25°C (GPa) | 4.5 |
| Property | Value |
|---|---|
| Die Shear Strength (LCP, SiN Chip) | 20 N/mm² (2,900 psi) |
Stronger Bonding. Cleaner Process. Reliable Performance. If you are looking for an adhesive that combines high adhesion strength, flexibility, and electronic safety, 3320-80 is the
Everwide FX219G5 Silicone Potting Compound – high-thermal, UL94 V-0 silicone potting for electronic modules. Compare with Shin-Etsu KET-132 silicone potting.
FX244-1 A specialized two-part silicone rubber designed for creating high-precision molds. This material features a unique oil-bleeding property that creates a self-releasing surface, eliminating the need for external non-stick sprays during demolding.
