3320-80 is a one-component, moisture curing modified silicone adhesive designed for bonding and sealing applications across plastics, metals, and glass. Utilizing an alkoxy curing system, the material cures upon exposure to atmospheric moisture, forming a flexible, durable elastomer.
Unlike traditional polyurethane systems containing isocyanates, 3320-80 offers a non-tin catalyst formulation compliant with environmental regulations (RoHS 2011/65/EU). It provides enhanced adhesion strength compared to conventional silicone adhesives, making it particularly suitable for demanding applications in the 3C (electronics) industry.
| Property | Value |
|---|---|
| Composition | Polyether resin |
| Appearance | Liquid |
| Color | Black |
| Viscosity (25°C, cps) | 80,000 – 160,000 |
| Specific Gravity | 1.4 |
| Solvent Content | 0% |
| Property | Value |
|---|---|
| Surface Dry Time (26°C, 57% RH) | ~7 minutes |
| Property | Value |
|---|---|
| Hardness (Shore A) | 60 |
| Young’s Modulus | 1.84 MPa |
| Elongation | 204% |
| Surface Resistivity | 1.9 × 10¹² ohm |
| Volume Resistivity | 2.0 × 10¹¹ ohm·cm |
| Glass Transition Temperature | < -50°C |
| Service Temperature Range | -40°C to 150°C |
| Substrate | Strength |
|---|---|
| Aluminum – Aluminum | 40 |
| Stainless Steel – Stainless Steel | 38 |
| Copper – Copper | 38 |
| PC – PC | 33 |
| PVC – PVC | 32 |
| PET – PET | 22 |
| PMMA – PMMA | 26 |
| ABS – ABS | 12 |
| PA – PA | 20 |
| Time | Depth |
|---|---|
| 1 day | 2.3 mm |
| 2 days | 3.0 mm |
| 3 days | 3.7 mm |
| 7 days | 5.3 mm |
