DOWSIL™ EA-5151 QiC Assembly Adhesive Clear is a one-component, neutral-cure, heat-assisted silicone adhesive with instant green strength. It offers high transparency, UV stability, and primerless adhesion to various substrates. The adhesive cures via moisture reaction and can be used with standard heat-assisted dispensing equipment.
This adhesive is designed for automotive electronics, industrial, and energy control applications, including:
| Property | Unit | Value |
|---|---|---|
| Appearance | – | Clear |
| Specific Gravity (uncured) | – | 1.08 |
| Viscosity at 100°C | Pa·s | 200 |
| Viscosity at 120°C | Pa·s | 70 |
| Non-volatile Content | % | >98.5 |
| Open Time | min | 15 |
| Lap Shear Adhesion (Aluminum, 21 Days) | MPa | 1.15 |
| Lap Shear Adhesion (FR4/PC/PMMA/PTFE, 21 Days) | MPa | 1.0 / 0.9 / 0.8 / 0.7 |
| Durometer (Shore A) | points | 60 |
| Ultimate Tensile Strength | MPa | 4.3 |
| Ultimate Elongation | % | 1300 |
| Linear Coefficient of Thermal Expansion (CTE) | ppm/°C | 230 |
| Dielectric Strength | kV/mm | 24 |
| Volume Resistivity | ohm·cm | 1E+16 |
| Dielectric Constant (100 Hz / 100 kHz) | – | 2.82 / 2.60 |
| Dissipation Factor (100 Hz / 100 kHz) | – | 0.0095 / 0.0012 |
| Light Transmittance (380 nm / 450 nm / 760 nm, 1 mm thickness) | % | 94 / 94 / 94 |
| Service Temperature | °C | -50 to 150 |
