1. Product Overview

• Description: A thermally conductive, liquid gap filler material designed for thermal management applications.
• Technology: Silicone-based.
• Appearance: Light blue (cured), Blue (Part A), White (Part B).
• Cure Type: Room temperature or heat cure.
• Mix Ratio (by weight & volume): 1:1 (Part A: Part B).
• Solids Content: 100%.
• Operating Temperature Range: -60 to 200°C.
• Features & Benefits:
  • Thermal conductivity of 3.5 W/m-K.
  • Low volatility for outgassing-sensitive applications.
  • Ultra-conforming with excellent wet-out for low-stress interface applications.
  • No cure by-products.
  • Forms a soft, form-in-place elastomer after curing.

2. Applications

• Industries:

  • Lighting
  • Automotive in-cabin electronics
  • Medical electronics
  • Industrial controls
  • Optics

• Application Methods:

  • Mixed and dispensed using dual-tube cartridge packs with static mixers and a manual or pneumatic gun.
  • Compatible with high-volume mixing and dispensing equipment.
