UCC A532 – Cleaner – Solder/Wave Pallets & Maintenance Cleaning

  • Item Name: UCC A532
  • Manufacturer: UCC
  • Technologies: Low-temperature, low-concentration flux remover with extended bath life
  • Color: Clear liquid
  • Cure Type: Not applicable
  • Package Size: 20L and 200L containers
  • Shelf Life: 5 years

1. Product Overview

UCC A532 is a cost-effective cleaning solution designed to remove baked-on flux from wave pallets and condensation traps. It operates at low concentrations and temperatures, offering extended bath life and reducing overall cleaning costs while increasing output.

2. Applications

  • Wave pallet cleaning
  • Condensation trap cleaning
  • Removal of low solid flux residues
  • Removal of rosin-based flux residues
  • Removal of water-soluble flux residues
  • Baked-on flux removal

3. Typical Properties

Property Value
Appearance Clear liquid
Specific Gravity (@ 25°C) 1.0
pH Value 11.2
Flash Point None
Boiling Point 190°C
Cleaning Temperature 30-65°C
Application Concentration 15-20%
Cleaning Time 10-20 minutes
Solubility in Water Soluble

4. Recommended Process

  • Operating Concentration: < 20%
  • Operating Temperature: < 55°C
  • Rinsing: DI Water
  • Drying: Air Dry
