Brands: VHB™
Package size:
Shelf Life: 24 months
3M™ VHB™ Tape 4910 is a 0.040 inch (1.0 mm) thick clear double coated acrylic foam tape with PE film liner. The
general purpose acrylic adhesive on both sides bonds to a broad range of high surface energy substrates including
metals, glass and easier to bond paints and plastics. The clear tape is good for bonding transparent or translucent
materials or for applications where colorless is a benefit. 3M™ VHB™ Tape 4910 is part of the 4910 tape family. Each
product in this family has general purpose acrylic adhesive and firm foam but varies in thickness.
Product Features
• Fast and easy-to-use permanent bonding method provides high strength and long-term durability
• Virtually invisible fastening keeps surfaces smooth
• Can replace mechanical fasteners (rivets, welds, screws) or liquid adhesives for transparent applications
• Clear, 0.040 in (1.0 mm), general purpose adhesive and clear acrylic core
• Eliminate drilling, grinding, refinishing, screwing, welding and associated clean-up
• Creates a permanent seal against water, moisture and more
• Pressure sensitive adhesive bonds on contact to provide immediate handling strength
• Allows the use of thinner, lighter weight and dissimilar materials
Recommended Applications
| Attribute Name | Test Method | Value |
| Color | Clear | |
| Adhesive Type | General Purpose Acrylic | |
| Foam Type | Solid Acrylic | |
| Density | ASTM D3574 | 960 kg/m³ (60 lb/ft³) ¹ |
| Total Tape Thickness | ASTM D3652 | 1 mm (40 mil) (0.04 in) |
| Thickness Tolerance | ±10 % |
¹ Foam with adhesive
| Attribute Name | Value |
| Liner | PE Film |
| Primary Liner Color | Red (printed) |
| Liner Thickness | 0.13 mm (0.005 in) |
Temperature: 23 °C (73 °F) Dwell Time: 72 h
| Attribute Name | Test Method | Substrate | Backing | Value |
| Normal Tensile | ASTM D897 | Aluminum | 690 kPa (100 lb/in²) ¹ | |
| 90° Peel Adhesion | ASTM D3330 | Stainless Steel | 5 mil Aluminum Foil | 26 N/cm (15 lb/in) ² |
| Overlap Shear
Strength |
ASTM D1002, ISO
4587 |
Stainless Steel | 480 kPa (70 lb/in²) ³ |
¹ 6.45 cm² (1 in²), Jaw Speed 51 mm/min (2 in/min)
² 304 mm/min (12 in/min)
³ 6.45 cm² (1 in²), Jaw Speed 12.7 mm/min (0.5 in/min)
