Brands: VHB™
Package size: Standard Length 32.9 m
Minimum Width 6.4 mm
Maximum Width 1219 mm
Core Size (ID) 76.2 mm (3 in)
Shelf Life: 24 months
3M™ VHB™ Tape 4611 is a 0.045 inch (1.1 mm) thick dark gray double-sided acrylic foam tape with PE film liner. The general purpose acrylic adhesive on both sides bonds to a broad range of high surface energy substrates including metals, glass and easier to bond paints and plastics. The firm foam provides high foam strength and has high temperature resistance. 3M™ VHB™ Tape 4611 is part of the 4611 tape family. Each product in this family has general purpose acrylic adhesive but varies in thickness.
| Attribute Name | Test Method | Value |
| Color | Dark Gray | |
| Adhesive Type | General Purpose Acrylic | |
| Foam Type | Firm Acrylic | |
| Density | ASTM D3574 | 840 kg/m³ (52 lb/ft³) ¹ |
| Total Tape Thickness | ASTM D3652 | 1.1 mm (45 mil) (0.045 in) |
| Thickness Tolerance | ±10 % |
¹ Foam with adhesive
| Attribute Name | Value |
| Liner | PE Film |
| Primary Liner Color | Red |
| Liner Thickness | 0.13 mm (0.005 in) |
Temperature: 23 °C (73 °F) Dwell Time: 72 h
| Attribute Name | Test Method | Substrate | Backing | Value |
| 90° Peel Adhesion | ASTM D3330 | Stainless Steel | 5 mil Aluminum Foil | 32 N/cm (18 lb/in) ¹ |
| Normal Tensile | ASTM D897 | Aluminum | 620 kPa (90 lb/in²) ² | |
| Overlap Shear
Strength |
ASTM D1002, ISO
4587 |
Stainless Steel | 450 kPa (65 lb/in²) ³ |
¹ 304 mm/min (12 in/min)
² 6.45 cm² (1 in²), Jaw Speed 51 mm/min (2 in/min)
³ 6.45 cm² (1 in²), Jaw Speed 12.7 mm/min (0.5 in/min)
Substrate: Stainless Steel Test Method: ASTM D3654
| Temperature | Value |
| 23 °C (73 °F) | 1,500 g ¹ |
| 121 °C (250 °F) | 500 g ¹ |
| 177 °C (350 °F) | 500 g ¹ |
| 66 °C (150 °F) | 500 g ¹ |
| 93 °C (200 °F) | 500 g ¹ |
¹ Tested at various temperatures and gram loadings. 3.23 cm² (0.5 in²). Will hold listed weight for 10,000 minutes (approximately 7 day).
| Attribute Name | Value |
| Short Term Temperature Resistance | 232 °C (450 °F) ¹ |
| Long Term Temperature Resistance | 149 °C (300 °F) ² |
¹ No change in room temperature dynamic shear properties following 4 hour conditioning at indicated temperature with 100 g/static load. (Represents minutes, hour in a process type temperature exposure).
² Maximum temperature where tape supports at least 78g/cm² (500 g/in²) in static shear for 10,000 minutes. (Represents continuous exposure for day or weeks).
